Gear Shapers

Gear Shapers
Gear Shapers
Product Code : 38
Brand Name : OMEGA
Product Description

Owing to our 61 years of industrial experience, We have been recognized as one of the affluent manufacturers, exporters and suppliers of an advanced range of Gear Shapers. Suitable for diverse mechanical applications, the machines provided by us are extensively demanded for shaping the metal piece and carve out required designs. Our offered machines are manufactured with high precision using excellent quality components and innovative technology in tune with international quality standards. In addition to this, the provided Gear Shapers can be availed from us in bulk at highly competitive prices with no hassle.

Features:

  • Long operational life
  • Sturdy construction
  • Rust proof body
  • Excellent functionality

STANDARD ACCESSORIES

  • Swivel Base Vice
  • Automatic Lubrication
  • Electrical & Guards

Technical Specifications:

Model

AG-24/CPB 24

AG-30 /CPB 30

Capacity

24''

30''

Adjustable Stroke

610

750

Length of Ram

1219

1425

Length x Width of Ram bearing

1000x280

1025x380

Max. & Min. Distance from Table to Ram

450x89

475x89

Table

Working Surface of Table

600x350

750x375

Max. Table Travel Horizontal

700

900

Max. Table Travel Vertical

380

400

Angular Movement of table of either sides

60o

30o

Tool Head

Max. Size of Tool Shank Accomodated

50x21

75x25

Max. Vertical Travel of Tool Slide

200

200

Max. Swivel of Tool Head on either side

60o

60o

Base

Length x Width of Base

1600x584

1800x625

Speeds & Feeds

(A) Cone Pulley Balt Drive (CPB)



NO. of Ram Speeds

4

4

Range of Speeds

12 to 50 SPM

10 to 40 SPM

Range of Table Feed per Stroke of Ram



(B) All Geared (AG)



No. of Ram Speeds

4

4

Range of Ram Speeds

12, 24, 40, 72 SPM

12, 24, 40, 72 SPM

Range of Table Feed per Stroke of Ram

0.009''

0.009''

Drive & Electrical Equipments

3/40/50 AC Electric Motor

3 HP

5 HP

Specification of Vice

Width x Opening x Depth of Jaws

200x275x62

250x325x75

Overall Dimensions

Length

2100

2500

Width

1200

1500

Height

1500

1600

Net Weight (Approx.)

Weight (Approx)

1800Kgs

2100Kgs
